Discover the Top 07 Architecture Patterns used in Modern Enterprise Software Development

Developing software without an architecture pattern may have been an option back then. However, that’s not the case anymore. Custom software development requires apps to be flexible, scalable, and maintainable. And that’s what architectural patterns are designed for. A software architecture pattern outlines the organization and high-level structure of an app. It defines the layout and organization of components and their interactions in software systems. Since there are several ways to organize components in a software system, different architectural patterns are designed for different use cases. Implementing architecture patterns is especially crucial for enterprise applications. They enable developers to build a robust enterprise software application. These apps can be easily scaled as the user base grows and demand increases.

Here are 7 architecture patterns used in enterprise applications or enterprise software application development:

Monolithic Architecture

Abstract representation of Monolithic Architecture in modern software development, showcasing a unified, imposing structure symbolizing a single codebase with interconnected components for enterprise applications.

Characteristics of Monolithic Architecture

Monolithic architecture is the old way of developing apps. It involves creating an app as a single unit where different components and functions are tightly coupled. This means you must deploy and execute all components of the app together as a single codebase.

Usage

While large-scale modern apps typically don’t use monolithic architecture, you can implement it in a small app that doesn’t need to be scaled. Monolithic architecture is generally more suitable for simpler apps, where components don’t change frequently or need independent scaling.

Pros

• Makes it easier to monitor performance and handle caching and logging
• Monolithic architecture may save time as it involves only one deployment. The entire app is built and deployed as a single codebase.
• For smaller systems, this architecture can be efficient, particularly when combined with software architecture for marketing AEC (architecture, engineering, and construction) as it keeps system design compact and manageable.

Cons

• To make changes in a monolithic app, you would have to update the entire codebase. Changes in one part or component will affect the entire app.
• It’s challenging to scale up and maintain a monolithic app due to code complexity.
• In a monolithic architecture, implementing new technologies and frameworks is challenging. This makes it difficult to integrate newer software for architecture design or other specialized architectural design software for beginners.

Microservices Architecture

Enterprise software application development – Microservices Architecture pattern for building enterprise applications

Microservices architecture enables developers to build applications as a set of services. These apps consist of various loosely coupled components or services. Each service in a microservices architecture has its own codebase that can be executed as a single unique function. Thus, developers can deploy each service independently.

Usage

Microservices architecture is widely used for enterprise software application development. It is also suitable for apps that require rapid development and scaling. Microservices can be integrated effectively into systems requiring specific components to function independently, such as software architecture for CDP (Customer Data Platforms).

Examples of Enterprise Software Applications using Microservices Architecture

Many enterprises that were using Monolithic architecture shifted to microservices once their system grew and code became complicated. Here are examples of companies using microservices architecture:

• Amazon
• Coca Cola
• eBay
• Netflix
• Etsy

Microservices Architecture: Code Examples

For example, we can create two microservices for an app. One service will handle user-related operations, and the other will handle product-related operations.

// User Microservice
let users = [];
app.use(bodyParser.json());

// Endpoint for creating a new user
app.post('/users', (req, res) => {
    const { name, email } = req.body;
    const newUser = { id: users.length + 1, name, email };
    users.push(newUser);
    res.status(201).json(newUser);
});

// Product Microservice
let products = [];
app.use(bodyParser.json());

// Endpoint for creating a new product
app.post('/products', (req, res) => {
    const { name, price } = req.body;
    const newProduct = { id: products.length + 1, name, price };
    products.push(newProduct);
    res.status(201).json(newProduct);
});

In the above code examples, each microservice has its own independent codebase. They can communicate with each other over HTTP requests.

Pros

• Splits the app into various independent services or components that can be deployed independently. This accelerates app development as various teams can work on a single app simultaneously.
• Maintaining each independent service is easier than maintaining the entire codebase.
• Each microservice can be scaled independently. Thus, apps built using the microservices architecture are highly scalable.
• Changes made in one part of the enterprise software application don’t affect the entire app. This makes architecture design for software project more flexible and adaptive to changes in requirements.

Cons

• Microservices increase the app’s architectural complexity. You would have to scale, secure, and deploy each service independently.
• Cannot be implemented in every application. Some apps include functions that cannot be split into independent units.

Event-Driven Architecture

In Event-Driven Architecture (EDA), components or services of an app or software are triggered based on events. These decoupled components can receive and process events asynchronously. This architecture pattern is focused on data that describe events, such as the pressing of a button or shopping cart abandonment. Thus, EDA is best suited for building e-commerce sites and user interfaces.

Real-World Examples of Event-Driven Architecture

Systems using the event-driven architecture can efficiently react to real-world events. Moreover, the architecture makes communication asynchronous. Thus, many companies have adopted the architecture to enhance operations and improve scalability. Here are real-world examples of companies that have implemented the event-driven architecture:

• Uber
• Unilever
• EDEKA
• JobCloud

Pros

• Promotes agility. Changes in one service or component don’t affect other components.
• Failure of one service doesn’t cause other services to fail.
• Reduced network bandwidth usage and CPU consumption as services utilize resources only when events are triggered.
• Facilitates parallel processing of events, improving efficiency and scalability.

Cons

• Structuring error handling can become challenging when multiple functions/modules are handling the same events.
• Managing several events across different business operations and processes can be complex and challenging.

Serverless Architecture

Enterprise software application – Serverless Architecture/Cloud Computing Model

Serverless enterprise architecture patterns is a software development approach that allows us to develop and run apps without managing the infrastructure. Software developers write and deploy the app’s code. However, the app runs on servers provided and managed by a cloud service provider, such as AWS.

Usage

Applications or systems with unpredictable workloads can hugely benefit from serverless architecture as they can easily scale resources as needed. Moreover, the architecture simplifies operational management and reduces costs.

Pros

• Maintaining and scaling the servers is the responsibility of the cloud service provider.
• Cost-effective. Cloud providers usually charge on a per-per-use basis. This means you don’t have to pay for unused servers or virtual machines.
• Saves time and accelerates development since developers don’t have to worry about maintaining the underlying infrastructure.
• Easily scales up or down resources depending on demand and the app’s requirements.

Cons

• Limited control over the underlying infrastructure. If there is a data center outage or fault in hardware, you have to depend on the cloud provider to fix it.
• Security concerns as various customers/organizations may use the same servers.

Service-Oriented Architecture (SOA)

SOA or Service-oriented architecture involves using various services or software components to build an app. Services are capable of communicating with one another, even across various platforms. SOA basically allows developers to build reusable independent services, which they can use in various systems or combine multiple services to perform complex tasks.

Usage

SOA is suitable for systems where you can call a single common service to perform a specific task. For example, it can be used in electronic health record systems and patient management systems to perform patient registration using a single service. Similarly, SOA can be implemented in a banking system, where we can have separate services for processing transactions, customer management, and account management.

Pros

• Since services can be reused across systems and business processes, SOA accelerates app development.
• Saves time, effort, and cost by enabling developers to build reusable services and software components.
• Testing, maintaining, and updating various smaller services is easier than an entire codebase.

Cons

• Implementing SOA can be complex and challenging.
• Ensuring the quality, performance, and security of services requires robust management and governance.
• SOA can cause scalability issues as it requires a centralized database to function.

Containerization and Kubernetes

Enterprise software application – Containerization and Kubernetes

Containerization is essentially a software deployment process. It involves packaging an app and its dependencies into a container. The container contains everything needed to run the application. This includes code, runtime, frameworks, libraries, and configuration files.

Kubernetes

Kubernetes, also called K8s, is a widely used platform for efficiently managing services enclosed within containers. The open-source platform is designed to automate various time-consuming manual processes. These include deployment, management, and scaling.

Pros

• Containerization simplifies app deployment and management. It provides a standardized runtime environment.
• Containerization and Kubernetes promote portability. They enable apps to run consistently across different environments.
• Kubernetes offers automated scaling capabilities. This means applications can scale dynamically in response to changes in workload demand.

Cons

• There are security concerns associated with the use of containers. This is because containers use the same kernel as the host OS.
• Networking in containerized environments can be complex.
• Implementing containers in enterprise software applications can be complex and involves a steep learning curve.

Reactive Architecture

Reactive architecture allows us to build responsive, flexible, and resilient systems based on reactive programming. Systems based on this architecture can react to events and changes in real-time, thus providing interactive user experiences.

Pros

• Reactive systems respond quickly to user requests, providing interactive user experiences.
• These systems efficiently adapt to changing conditions and are designed to recover quickly from failures.
• Reactive architecture enables systems to scale efficiently to handle increasing loads.

Cons

• Building reactive systems requires expertise in asynchronous programming, distributed systems, and message passing.
• Implementing reactive architecture may involve a steep learning curve.

Real-World Examples of Applications Built Using Reactive Architecture

Many organizations have implemented the principle of Reactive architecture to build efficient reactive systems. Here are some real-world examples of apps/systems using the Reactive architecture:

• LinkedIn
• Walmart Canada
• Capital One auto loan application
• Verizon Wireless

Conclusion

A software architecture pattern defines the macro-level structure of an application or software. It outlines the fundamental organization and high-level structure of a software app or system. Using an architecture pattern for enterprise software Development is crucial. It allows us to build flexible, scalable, and maintainable systems/apps. However, there are various architectural patterns designed for different use cases. In this article, we’ve discussed 7 common architecture patterns for enterprise software application development. These include:

• Monolithic Architecture
• Microservices Architecture
• Event-Driven Architecture (EDA)
• Serverless Architecture
• Service-Oriented Architecture (SOA)
• Containerization and Kubernetes
• Reactive Architecture

FAQs

WHAT IS THE BEST 3D MODELING SOFTWARE FOR ARCHITECTURE?

The best 3D modeling software for architecture includes tools like AutoCAD, Revit, and SketchUp, which are highly regarded for architectural design and modeling capabilities.

WHAT IS THE BEST CAD SOFTWARE FOR ARCHITECTURE?

AutoCAD is widely considered the best CAD software for architecture due to its versatility, extensive features, and industry adoption.

WHICH IS THE BEST SOFTWARE FOR ARCHITECTURE?

The best software for architecture combines design, drafting, and visualization tools. Some of the top choices include AutoCAD, Revit, and Rhino, depending on the type of project and requirements.

WHAT IS THE BEST SOFTWARE FOR ARCHITECTURAL DESIGN?

Software like AutoCAD, Rhino, and ArchiCAD is best for architectural design, as they provide powerful design and modeling tools for creating detailed plans and visualizations.

HOW TO GET ARCHITECTURE SOFTWARE FOR FREE?

There are several free or open-source options for architecture software, such as FreeCAD, SketchUp Free, and Blender, which can help you get started with architectural projects without any cost.

IS MICROSERVICES ARCHITECTURE GOOD FOR SERVER SOFTWARE?

Yes, microservices architecture is suitable for server software because it offers scalability, independence for each service, and more efficient deployment, making it a good choice for complex and growing systems.

WHAT ARE THE SEVERAL LANGUAGES FOR DESCRIBING SOFTWARE ARCHITECTURES?

Common languages used for describing software architectures include UML (Unified Modeling Language), ArchiMate, and SysML (Systems Modeling Language), each designed for specific architectural representation needs.

WHAT SHOULD YOU ANALYZE FOR ARCHITECTURE DESIGN IN SOFTWARE ENGINEERING?

When analyzing software architecture, focus on scalability, maintainability, performance, and security. These factors will ensure the software architecture can handle future growth and requirements.

WHAT SOFTWARE SHOULD I LEARN FOR ARCHITECTURE?

Architectural software tools like AutoCAD, Revit, Rhino, and SketchUp are essential for architects, with each catering to different aspects of architectural design, modeling, and drafting.

WHY IS SOFTWARE ARCHITECTURE IMPORTANT FOR ORGANIZATIONS?

Software architecture is critical because it ensures a system’s scalability, reliability, and maintainability. A well-structured architecture can lead to better resource management, faster deployment, and cost savings in the long term.
